# Boolean value for y-coordinate?

While implementing the feature of signing and verification with ES256 / ES384 / ES512 algorithms into my Java library for CBOR / COSE / CWT (authlete/cbor), I noticed that “IANA COSE Key Type Parameters” states that the y-coordinate of EC2 keys can be represented as a boolean value instead of an integer value.

Through an internet search, I found the following sentence in “2.3.3 Elliptic-Curve-Point-to-Octet-String Conversion” of “SEC 1: Elliptic Curve Cryptography”.

Derive from yP a single bit ỹP as follows (this allows the y-coordinate to be represented compactly using a single bit)

When the y-coordinate is represented as a single bit (which can be represented as a boolean value), the actual value of the y-coordinate needs to be calculated using other parameters such as the x-coordinate and elliptic curve parameters.

In the case of “prime finite fields”, which is the case for P-256, P-384 and P-521 (which are elliptic curves used by ES256, ES384 and ES512 algorithms, respectively), the y-coordinate (yp) is calculated by the following steps as instructed in “2.3.4 Octet-String-to-Elliptic-Curve-Point Conversion”.

1. Compute the field element αx³p + axp + b (mod p)
2. Compute a square root β of α modulo p
3. Output “invalid” and stop if there are no square roots of α modulo p
4. Otherwise set yp = β if βp (mod 2), and set yp = p - β if βp (mod 2)

I implemented the calculation steps (`uncompressY()` in ECDSA.java) based on a certain answer found on Stack Overflow. But, to be honest, I haven’t tested it yet, so I’m not sure if it’s a correct implementation.

# DER or P1363?

The algorithm results in a pair of integers (R, S). There are two major ways to encode the two integers into a byte array. One is DER and the other is P1363.

If you pass `"SHA256withECDSA"` to the `getInstance(String)` method of the `java.security.Signature` class, the returned `Signature` instance presumes that the format of signatures is DER.

`"SHA256withECDSAinP1363Format"` should be specified instead to create a `Signature` instance for the P1363 format, which is adopted by COSE ECDSA (RFC 9053, 2.1. ECDSA).

--

--
